Description

Material Transmitter:Stainless steel top housing (AISI 316)
and coated brass bottom.
Sensor: Carbon steel
Approvals WRAS, KTW, DVGW 270, ACS, Belgaqua, NSF/ANSI Standard 61,
MID (EU), OIML R49, MCERTS Sira Certificate No. MC080137/00
NMI 10

Benefits

  • Simple meter placement – floating chamber IP 68 (NEMA 6P) design ensures continuous filterless performance regardless of position or in-line piping stresses, even when buried underground
  • Low pressure loss – unrestricted flow tube ensures minimal pressure loss even at high flow rates and reduces overall network system pressure, helping to prevent leakage from burst pipes and excess stress placed on pumping stations
  • Zero maintenance – no moving parts and up to 15-year battery life with external 4-D cell battery pack
  • Bi-directional measurement – only one meter required for measurement in both directions
  • Installation requires 0D inlet to and outlet from the sensor – eliminating concerns about where the meter is installed
  • Intelligent meter – capable of leak detection, data logging and error self-detection
  • Remote capabilities – stay up-to-date on measurement data without having to visit the site through optional 3G/UMTS Wireless Communication Module
