Description

Programmable Logic Controller

Siemens LOGO 230 RCE logic module requires external fuse for short-circuit protection. It has 2-Hz with resistive load and 0.5-Hz with inductive load switching frequency. It is a 4-relay output with 85-265-Volt AC and 100 to 253-Volt DC permissible range. It has eight inputs and 4 outputs and module can be DIN rail or wall mounted. It is IP20 rated for finger protection. Module is UL listed, CSA/CE/FM/VDE certified and meets IEC/EN standards.

  • LOGO! 230RCE
  • Logic module with display
  • Voltage supply: 115/230 V AC/relay
  • 8 DI (Digital Inputs),4 DO (Digital Outputs)
  • Memory: 400 blocks
  • expandable
  • Ethernet
  • Integral web server
  • Data logging
  • Standard micro SD card
  • For LOGO! SOFT COMFORT from version 8
  • Older projects executable
